PCSDR74-151M-RC
ObsoleteAllied Components International
150UH +/-20% POWER CHIP INDUCTOR
PCSDR74-151M-RC
ObsoleteAllied Components International
150UH +/-20% POWER CHIP INDUCTOR
Description
General part information
PCSDR74-151M-RC
150 µH Shielded Wirewound Inductor 693 mA 709.2mOhm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCSDR74-151M-RC |
|---|---|
| Current - Saturation (Isat) | 812 mA |
| Current Rating | 693 mA |
| DC Resistance (DCR) (Max) | 709.2 mOhm |
| Height - Seated (Max) | 0.177 in |
| Inductance | 150 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension Length | 0.287 in |
| Size / Dimension Width | 0.287 in |
| Tolerance | 20 % |
| Type | Wirewound |
