SRFWG018-100

Active

Antenova

RF ANT 1.561/1.575GHZ FLAT 100MM

Search across all available documentation for this part.

Active

Antenova

RF ANT 1.561/1.575GHZ FLAT 100MM

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1000	$ 3.07

General part information

RF ANTENNA Bluetooth, GNSS, Wi-Fi Flat Patch U.FL (UMCC), IPEX MHF1 (2) Adhesive

Technical documentation and resources

Parameters and characteristics commom to parts in this series

RF ANT 1.561/1.575GHZ FLAT 150MM

Part	VSWR	Frequency Range [Max]	Frequency Range [Min]	Mounting Type	Return Loss	RF Family/Standard	Frequency Group [Max]	Frequency Group [Min]	Height (Max)	Height (Max) [Max]	Features	Applications	Antenna Type	Termination	Number of Bands	Features	Gain
Antenova SRFWG018-150	1.4	1.609 GHz, 2.5 GHz	1.559 GHz, 2.4 GHz	Adhesive	-18 dB	Bluetooth, Navigation, WiFi	2 GHz, 3 GHz	1 GHz, 2 GHz	0.15 mm	0.006 in	Cable - 150mm	Bluetooth, GNSS, Wi-Fi	Flat Patch	IPEX MHF1 (2), U.FL (UMCC)	2
Antenova SRFWG018-100	1.4	1.609 GHz, 2.5 GHz	1.559 GHz, 2.4 GHz	Adhesive	-18 dB	Bluetooth, Navigation, WiFi	2 GHz, 3 GHz	1 GHz, 2 GHz	0.15 mm	0.006 in	Cable	Bluetooth, GNSS, Wi-Fi	Flat Patch	IPEX MHF1 (2), U.FL (UMCC)	2	100 mm
