LP2-5-1-A
ActiveSwitch Components
LED INDICATOR 5MM-AMBER, SNAP-IN
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
LP2-5-1-A
ActiveSwitch Components
LED INDICATOR 5MM-AMBER, SNAP-IN
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | LP2-5-1-A | LP2-5 Series |
|---|---|---|
| Lamp Color | Amber | Green, Amber, Red |
| Lens Color | Amber | Green, Amber, Red |
| Lens Size [diameter] | 5 mm Dia | 5 mm Dia |
| Lens Transparency | Clear | Clear |
| Panel Cutout Dimensions | 0.49 in | 0.49 in |
| Panel Cutout Dimensions | 12.5 mm | 12.5 mm |
| Panel Cutout Shape | Round | Round |
| Termination Style | Quick Connect - 0.250" (6.3mm) | Quick Connect - 0.250" (6.3mm) |
| Type | LED | LED |
LP2-5 Series
LED INDICATOR 5MM-GREEN, SNAP-IN
| Part | Lens Transparency | Lens Color | Lens Size [diameter] | Panel Cutout Dimensions | Panel Cutout Dimensions | Panel Cutout Shape | Type | Lamp Color | Termination Style |
|---|---|---|---|---|---|---|---|---|---|
Switch Components LP2-5-1-G | Clear | Green | 5 mm Dia | 0.49 in | 12.5 mm | Round | LED | Green | Quick Connect - 0.250" (6.3mm) |
Switch Components LP2-5-1-A | Clear | Amber | 5 mm Dia | 0.49 in | 12.5 mm | Round | LED | Amber | Quick Connect - 0.250" (6.3mm) |
Switch Components LP2-5-1-R | Clear | Red | 5 mm Dia | 0.49 in | 12.5 mm | Round | LED | Red | Quick Connect - 0.250" (6.3mm) |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 3.49 | |
| 10 | $ 2.98 | |||
| 25 | $ 2.47 | |||
| 50 | $ 2.24 | |||
| 100 | $ 1.99 | |||
| 250 | $ 1.83 | |||
| 500 | $ 1.66 | |||
| 1000 | $ 1.50 | |||
Description
General part information
LP2-5 Series
LED Panel Indicator Amber Clear Quick Connect - 0.250" (6.3mm)
