0678H9400-02
ActiveBel Fuse Inc.
FUSE CHIP 40A 250V SMD SOLDER PAD 3912 9.8 X 3.05 X 3.05MM CERAMIC T/R AUTOMOTIVE AEC-Q200
0678H9400-02
ActiveBel Fuse Inc.
FUSE CHIP 40A 250V SMD SOLDER PAD 3912 9.8 X 3.05 X 3.05MM CERAMIC T/R AUTOMOTIVE AEC-Q200
Description
General part information
0678H9400-02
40 A 250 V AC 125 V DC Fuse Board Mount (Cartridge Style Excluded) Surface Mount 2-SMD, Square End Block
Technical Specifications
Parameters and characteristics for this part
| Specification | 0678H9400-02 |
|---|---|
| Approval Agency | cURus, AEC-Q200 |
| Breaking Capacity (AC) | 100 A |
| Breaking Capacity (DC) | 1 kA |
| Current Rating | 40 A |
| DC Cold Resistance | 0.0015 Ohms |
| Fuse Type | Board Mount (Cartridge Style Excluded) |
| Melting I²t | 1000 |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 2-SMD, Square End Block |
| Size / Dimension Height | 0.12 in |
| Size / Dimension Length | 0.386 in |
| Size / Dimension Width | 0.12 in |
| Voltage Rating - AC | 250 V |
| Voltage Rating - DC | 125 V |
