1800331
ActivePhoenix Contact
TERM BLOCK HDR 18POS VERT 3.81MM
1800331
ActivePhoenix Contact
TERM BLOCK HDR 18POS VERT 3.81MM
Description
General part information
1800331
18 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1800331 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.134 in |
| Current - IEC | 8 A |
| Current - UL | 8 A |
| Header Orientation | Vertical |
| Insulation Height | 0.362 in |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 18 |
| Pitch | 0.15 in |
| Positions Per Level | 18 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 160 V |
| Voltage - UL | 300 V |
