Y1073200R000F9L
ActiveVPG Foil Resistors
Z202T 200R00 1.0%
Y1073200R000F9L
ActiveVPG Foil Resistors
Z202T 200R00 1.0%
Description
General part information
Y1073200R000F9L
200 Ohms ±1% 0.25W, 1/4W Through Hole Resistor Radial Non-Inductive Metal Foil
Technical Specifications
Parameters and characteristics for this part
| Specification | Y1073200R000F9L |
|---|---|
| Composition | Metal Foil |
| Features | Non-Inductive |
| Height - Seated (Max) | 0.26 in |
| Number of Terminations | 2 |
| Operating Temperature (Max) | 175 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | Radial |
| Package Name | Radial |
| Power (Watts) | 250 mW |
| Power (Watts) Options | 1/4W |
| Resistance | 200 Ohm |
| Size / Dimension Length | 0.25 in |
| Size / Dimension Width | 0.125 in |
| Temperature Coefficient | 0.2 ppm/°C |
| Tolerance | 1 % |
