PC0503-331M-RC
ActiveAllied Components International
330UH +/-20% POWER CHIP INDUCTOR
PC0503-331M-RC
ActiveAllied Components International
330UH +/-20% POWER CHIP INDUCTOR
Description
General part information
PC0503-331M-RC
330 µH Unshielded Wirewound Inductor 280 mA 3.2Ohm Max Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PC0503-331M-RC |
|---|---|
| Current Rating | 0.28 A |
| DC Resistance (DCR) (Max) | 3.2 Ohm |
| Height - Seated (Max) | 0.13 in |
| Inductance | 330 µH |
| Inductance Frequency - Test | 1 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 0.228 in |
| Size / Dimension Width | 0.205 in |
| Tolerance | 20 % |
| Type | Wirewound |
