Specification	380LQ472M100A032

Applications	General Purpose
Capacitance	4700 µF
ESR (Equivalent Series Resistance)	71 mOhm
Height - Seated (Max)	1.457 in
Lead Spacing	0.394 in
Lifetime	2000 Hrs
Mounting Type	Through Hole
Operating Temperature (Max)	85 °C
Operating Temperature (Min)	-40 °C
Package / Case	Can - Snap-In, Radial
Polarization	Polar
Ripple Current	5.13 A, 5.9 A
Size / Dimension Diameter	1.378 in
Tolerance	20 %
Voltage - Rated	100 VAC/DC
