9998 008500

Active

Belden Inc.

CABLE 3COND 16AWG GRAY

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 3COND 16AWG GRAY

Technical Specifications

Parameters and characteristics for this part

Specification	9998 008500

Cable Type	Multi-Conductor
Conductor Insulation	Polyethylene (PE)
Conductor Material	Copper, Bare
Conductor Strand [custom]	34 AWG
Conductor Strand [custom]	65
Jacket (Insulation) Diameter [diameter]	12.07 mm
Jacket (Insulation) Diameter [diameter]	0.475 in
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Thickness	1.143 mm
Jacket (Insulation) Thickness	0.045 in
Jacket Color	Gray
Length [x]	500 '
Length [x]	152.4 m
Number of Conductors	3
Ratings	UL Style SJT
Usage	Cord and Cordset
Voltage	300 V
Wire Gauge	16 AWG

Part	Conductor Strand [custom]	Conductor Strand [custom]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Insulation	Conductor Material	Jacket (Insulation) Material	Cable Type	Number of Conductors	Length [x]	Length [x]	Wire Gauge	Usage	Voltage	Jacket Color	Ratings
Belden Inc. 9998 008500	34 AWG	65	12.07 mm	0.475 in	1.143 mm	0.045 in	Polyethylene (PE)	Copper Bare	Poly-Vinyl Chloride (PVC)	Multi-Conductor	3	500 '	152.4 m	16 AWG	Cord and Cordset	300 V	Gray	UL Style SJT

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	500	$ 9.21

General part information

3 Conductor Multi-Conductor Cable Gray 16 AWG 500.0' (152.4m)

Technical documentation and resources
