AP30-21JDZZZ000000

Active

Sifam Tinsley Instrumentation Inc

MULTI METER 1-5A/120V LCD PNL MT

Search across all available documentation for this part.

Active

Sifam Tinsley Instrumentation Inc

MULTI METER 1-5A/120V LCD PNL MT

Technical Specifications

Parameters and characteristics for this part

Specification	AP30-21JDZZZ000000

Display Characters - Height [z]	18.1 mm
Display Characters - Height [z]	0.713 in
Display Type	LCD - Red Characters
Features	Pulse Meter
Ingress Protection	IP54 - Dust Protected, Water Resistant
Measuring Type	Current (3-Phase), Wattage, Voltage
Number of Characters Per Row	4
Operating Temperature [Max]	70 °C
Operating Temperature [Min]	-20 C
Panel Cutout Dimensions [x]	92.8 mm
Panel Cutout Dimensions [y]	92.8 mm
Termination Style	Plug In Screw Terminals
Type	Multifunction Meter (Current, Voltage, Frequency, Power)
Voltage - Supply [Max]	48 V
Voltage - Supply [Min]	12 V
Weight	323.41 g
Weight	0.713 lb

MULTI METER 1-5A/120V LCD PNL MT

Part	Operating Temperature [Min]	Operating Temperature [Max]	Type	Display Type	Panel Cutout Dimensions [x]	Panel Cutout Dimensions [y]	Ingress Protection	Weight	Weight	Measuring Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Termination Style	Number of Characters Per Row	Features	Display Characters - Height [z]	Display Characters - Height [z]
Sifam Tinsley Instrumentation Inc AP30-21JDZZZ000000	-20 C	70 °C	Multifunction Meter (Current, Voltage, Frequency, Power)	LCD - Red Characters	92.8 mm	92.8 mm	IP54 - Dust Protected, Water Resistant	323.41 g	0.713 lb	Current (3-Phase), Voltage, Wattage	12 V	48 V	Plug In Screw Terminals	4	Pulse Meter	18.1 mm	0.713 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Retail Package	1	$ 275.00

General part information

Multifunction Meter (Current, Voltage, Frequency, Power) LCD - Red Characters Display Panel Mount
