289-726
ActiveWAGO Corporation
INTERFACE MODULE SUB-D F
289-726
ActiveWAGO Corporation
INTERFACE MODULE SUB-D F
Description
General part information
289-726
15 Position Interface Module Terminal Blocks - Screw Connection To D-Sub, Female 12-28 AWG
Technical Specifications
Parameters and characteristics for this part
| Specification | 289-726 |
|---|---|
| Control Side Cable Retainer Type | Jackscrew Socket |
| Control Side Connection Gender | Female |
| Control Side Connection Shape | D-Sub |
| Current Rating (Per Contact) | 2 A |
| Operating Temperature (Max) | 50 °C |
| Operating Temperature (Min) | -20 °C |
| Positions / Poles | 15 |
| Process Side Connection | Terminal Blocks, Screw Connection |
| Voltage - Rated | 50 V |
| Width | 1.713 in |
| Wire Gauge (AWG) (Max) | 28 AWG |
| Wire Gauge (AWG) (Min) | 12 AWG |
