Specification	9S0612P4S011

Approval Agency	cURus, TUV
Bearing Type	Ball
Fan Type	Tubeaxial
Features	PWM Control, Locked Rotor Protection, Speed Sensor (Tach)
Material - Blade	Plastic
Material - Frame	Plastic
Size / Dimension Height	60 mm
Size / Dimension Length	60 mm
Size / Dimension Shape	Square
Termination	4 Wire Leads
Termination Leads Count	4 leads
Termination Type	Wire Leads
Voltage - Rated	12 VAC
Width	25 mm

9S Type / Silent Ser Series

Part	Operating Temperature (Max)	Operating Temperature (Min)	Features	Approval Agency	Noise	Air Flow	Power (Watts)	Size / Dimension Length	Size / Dimension Shape	Size / Dimension Height	Termination Leads Count	Termination Type	Termination	RPM	Voltage - Rated	Width	Weight	Bearing Type	Static Pressure	Fan Type	Voltage Range (Min)	Voltage Range (Max)	Lifetime	Material - Blade	Material - Frame	Current Rating
Sanyo Denki America Inc. 9S0824L4021	158 °F	14 °F	Locked Rotor Protection	CSA TUV UL	16 dB	23.3 CFM	960 mW	80 mm	Square	80 mm	2 leads	Wire Leads	2 Wire Leads	2000 RPM	24 VAC	25 mm	0.167 lb	Ball	0.073 in H2O	Tubeaxial	10 VDC	26.4 VDC	40000 Hrs	Plastic	Plastic	40 mA
Sanyo Denki America Inc. 9S0824M401	158 °F	14 °F	Locked Rotor Protection Speed Sensor (Tach)	CSA TUV UL	22 dB	29.3 CFM	1.44 W	80 mm	Square	80 mm	3	Wire Leads	3 Wire Leads	2500 RPM	24 VAC	25 mm	0.167 lb	Ball	0.11 in H2O	Tubeaxial	10 VDC	26.4 VDC	40000 Hrs	Plastic	Plastic	60 mA
Sanyo Denki America Inc. 9S0824M4D01	158 °F	14 °F	Locked Rotor Sensor	CSA TUV UL	22 dB	29.3 CFM	1.44 W	80 mm	Square	80 mm	3	Wire Leads	3 Wire Leads	2500 RPM	24 VAC	25 mm	0.167 lb	Ball	0.11 in H2O	Tubeaxial	10 VDC	26.4 VDC	40000 Hrs	Plastic	Plastic	60 mA

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

3D models and CAD resources for this part

Technical documentation and resources

No documents available
