1903054
ActivePhoenix Contact
TERM BLOCK HDR 5POS VERT 3.81MM
1903054
ActivePhoenix Contact
TERM BLOCK HDR 5POS VERT 3.81MM
Description
General part information
1903054
5 Position Terminal Block Header, Male Pins, Shrouded (4 Side) 0.150" (3.81mm) Vertical Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1903054 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 0.134 in |
| Current - IEC | 8 A |
| Current - UL | 8 A |
| Header Orientation | Vertical |
| Insulation Height | 0.362 in |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Number of Positions | 5 |
| Pitch | 0.15 in |
| Positions Per Level | 5 |
| Termination Style | Solder |
| Type | Shrouded (4 Side), Male Pins, Header |
| Voltage - IEC | 160 V |
| Voltage - UL | 300 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
