5-827066-1

Active

TE Connectivity AMP Connectors

CONN D-SUB 9POS VERT SLDR

Search across all available documentation for this part.

Active

TE Connectivity AMP Connectors

CONN D-SUB 9POS VERT SLDR

Technical Specifications

Parameters and characteristics for this part

Specification	5-827066-1

Connector Style	D-Sub
Contact Type	Signal
Flange Feature	Housing/Shell (Unthreaded)
Mounting Type	Through Hole
Number of Positions	9
Number of Rows	2
Shell Size, Connector Layout [custom]	DE, E
Shell Size, Connector Layout [custom]	1
Termination	Solder

CONN D-SUB 9POS VERT SLDR

Part	Shell Size, Connector Layout [custom]	Shell Size, Connector Layout [custom]	Connector Style	Termination	Contact Type	Mounting Type	Flange Feature	Number of Rows	Number of Positions
TE Connectivity AMP Connectors 5-827066-1	DE, E	1	D-Sub	Solder	Signal	Through Hole	Housing/Shell (Unthreaded)	2	9

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

9 Position D-Sub Connector
