| Actuator Height off PCB, Vertical | - | 3.1 - 4.9 mm |
| Actuator Length | - | 3.8 - 27 mm |
| Actuator Length | - | Flush |
| Actuator Length, Right Angle | - | 1.46 mm |
| Actuator Marking | No Marking | No Marking, Varies by Cap |
| Actuator Material | - | Brass, Chrome Plated, Brass, Nickel Plated, Glass Filled, Polyamide (PA), Nylon, Polybutylene Terephthalate (PBT), Polyphenylene Sulfide (PPS), Polyacetal, Polybutylene Terephthalate (PBT), Glass Filled |
| Actuator Orientation | - | Top Actuated, Side Actuated |
| Actuator Type | Concave (Curved) | Standard Round, Flatted, Concave (Curved), Knurled, Round Button, Actuator Arm, Cap Required, Lever for Cap, Plunger for Cap, Locking Lever, Screwdriver Slot, Concave (Standard V), Standard, Standard Round with Cap, Round |
| Actuator Type | - | 3.17 - 6 mm |
| Angle of Throw | - | 30 - 45 ° |
| Approval Agency | UL, EN | UL, EN, CSA, VDE |
| Bushing Thread | - | M12, Unthreaded, Unthreaded, Square, M6 x 0.75 |
| Bushing Thread | - | 1 x 1 |
| Circuit | SPDT | DPDT, 4PDT, 3PDT, SPDT, SPST, 3PST, DPST, SPST-NO, SP3T |
| Circuit per Deck | - | SP11T, 4P3T |
| Circuit per Deck | - | DP6T |
| Circuit per Deck | - | SP12T, SP3T |
| Color - Actuator/Cap | Black | Black, Ivory, White |
| Contact Finish | - | Gold, Silver |
| Contact Material | - | Phosphor Bronze, Silver Alloy, Copper |
| Contact Rating @ Voltage | - | 0.05 - 24 A |
| Contact Timing | - | Non-Shorting |
| Current Rating (Amps) | 15 A | 0.4 - 250 A |
| Depth Behind Panel | - | 22 - 99 mm |
| Depth Behind Panel | - | 17 - 116.5 mm |
| Electrical Life | 10000 Cycles | 10000 - 100000 Cycles |
| Features | - | Epoxy Sealed Terminals, Process Sealed, Jumper needed to achieve triple throw, Sealed - Fully, White Cap, Low Temperature Lubricant, Black Actuator, Black Cap |
| Illumination | - | Non-Illuminated, Illuminated |
| Illumination Type, Color | - | LED, Yellow, Green, Red, White, Blue |
| Illumination Voltage (Nominal) | - | 1.8 - 2.1 VDC |
| Index Stops | - | Adjustable, Fixed |
| Ingress Protection | IP67 - Dust Tight, Waterproof | IP67 - Dust Tight, Waterproof, Dust Proof |
| Mechanical Life | 30000 Steps | 30000 - 5000000 Steps |
| Mounting Type | Panel Mount, Snap-In | Through Hole, Right Angle, Through Hole, Vertical, Right Angle, Panel Mount, Snap-In, Flange, Surface Mount, Right Angle, Surface Mount |
| Number of Decks | - | 2 - 5 |
| Number of Decks | - | 1 |
| Number of Poles per Deck | - | 1 - 2 |
| Number of Positions | - | 3 - 12 |
| Number of Positions | - | 2 |
| Operating Force | - | 157 - 265 gf |
| Operating Temperature | - | -10 °C |
| Operating Temperature | - | 50 - 158 °F |
| Operating Temperature [Max] | 85 °C | 50 - 85 °C |
| Operating Temperature [Min] | -25 °C | -30 - -10 ░C |
| Outline | - | 6.2 - 10 mm |
| Outline | - | 6.2 - 10.8 mm |
| Panel Cutout Dimensions | - | 0.25 - 12.5 mm |
| Panel Cutout Dimensions | - | 17.8 - 32 mm |
| Panel Cutout Dimensions | - | 10.1 - 19.8 mm |
| Switch Function | On-Off-Mom | On-Off-Mom, On-Mom, On-On, On-Off, Mom-Off-Mom, On-Off-On, Off-Mom, On-On-On, On-On-Mom, Mom-On-Mom |
| Switch Travel | - | 0.3 mm |
| Switch Travel | - | 0.25 mm |
| Termination Style | Wire Leads | Solder Lug, PC Pin, Quick Connect - 0.250" (6.3mm), Screw Terminal, Wire Wrap, Wire Leads, Gull Wing |
| Voltage Rating - AC | 125 V | 28 - 125 V |
| Voltage Rating - DC | 30 V | 28 - 30 V |
