EFX1S48K473C012LH
ActiveEaton - Electronics Division
CAP FILM 0.047UF 10% 1KVDC RAD
EFX1S48K473C012LH
ActiveEaton - Electronics Division
CAP FILM 0.047UF 10% 1KVDC RAD
Description
General part information
EFX1S48K473C012LH
0.047 µF Film Capacitor 480V 1000V (1kV) Polypropylene (PP), Metallized Radial
Technical Specifications
Parameters and characteristics for this part
| Specification | EFX1S48K473C012LH |
|---|---|
| Applications | RFI Suppression, EMI |
| Capacitance | 47 nF |
| Dielectric Material | Metallized, Polypropylene (PP) |
| Height - Seated (Max) | 0.63 in |
| Lead Spacing | 0.886 in |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 110 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Radial |
| Ratings | X1 |
| Size / Dimension Length | 1.024 in |
| Size / Dimension Width | 0.236 in |
| Termination | PC Pins |
| Tolerance | 10 % |
| Voltage Rating - AC | 480 VAC |
| Voltage Rating - DC | 1 kV |
