General part information
Pluggable Terminal Blocks 6 Pos 5.08mm pitch Through Hole Header
Technical documentation and resources
Parameters and characteristics for this part
| Specification | 1800774 |
|---|---|
| Color | Black |
| Contact Mating Finish | Tin |
| Contact Tail Length | 3.5 mm |
| Contact Tail Length | 0.138 in |
| Current - IEC | 10 A |
| Current - UL | 12 A |
| Header Orientation | Vertical |
| Insulation Height | 0.87 in |
| Insulation Height | 22.1 mm |
| Mounting Type | Through Hole |
| Number of Levels | 2 |
| Number of Positions | 12 |
| Pitch [x] | 0.2 in |
| Pitch [x] | 5.08 mm |
| Positions Per Level | 6 |
| Termination Style | Solder |
| Type | Header, Male Pins, Shrouded (2 Side) |
| Voltage - IEC | 250 V |
| Voltage - UL | 300 V |
Pluggable Terminal Blocks 6 Pos 5.08mm pitch Through Hole Header
| Part | Voltage - IEC | Color | Voltage - UL | Number of Levels | Current - IEC | Termination Style | Current - UL | Contact Tail Length | Contact Tail Length | Number of Positions | Pitch [x] | Pitch [x] | Mounting Type | Type | Positions Per Level | Header Orientation | Insulation Height | Insulation Height | Contact Mating Finish |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Phoenix Contact 1800774 | 250 V | Black | 300 V | 2 | 10 A | Solder | 12 A | 3.5 mm | 0.138 in | 12 | 0.2 in | 5.08 mm | Through Hole | Header, Male Pins, Shrouded (2 Side) | 6 | Vertical | 0.87 in | 22.1 mm | Tin |
