1095A 0105000
ActiveBelden Inc.
CABLE 36 COND 18AWG BLACK
Deep-Dive with AI
Search across all available documentation for this part.
1095A 0105000
ActiveBelden Inc.
CABLE 36 COND 18AWG BLACK
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | 1095A 0105000 | 1095A Series |
|---|---|---|
| Cable Type | Multi-Triad | Multi-Triad |
| Conductor Insulation | Polyamide (PA), Nylon, Poly-Vinyl Chloride (PVC) | Polyamide (PA), Nylon, Poly-Vinyl Chloride (PVC) |
| Conductor Material | Copper, Bare | Copper, Bare |
| Conductor Strand [custom] | 26 AWG | 26 AWG |
| Conductor Strand [custom] | 7 | 7 |
| Features | Rip Cord, Drain Wire | Rip Cord, Drain Wire |
| Jacket (Insulation) Diameter [diameter] | 0.94 in | 0.94 in |
| Jacket (Insulation) Diameter [diameter] | 23.88 mm | 23.88 mm |
| Jacket (Insulation) Material | Poly-Vinyl Chloride (PVC) | Poly-Vinyl Chloride (PVC) |
| Jacket (Insulation) Thickness | 2.108 mm | 2.108 mm |
| Jacket (Insulation) Thickness | 0.083 in | 0.083 in |
| Jacket Color | Black | Black |
| Length | - | 7500 ft |
| Length | - | 2286 m |
| Length | - | 2500 ft |
| Length | - | 762 m |
| Number of Conductors | 36 | 36 |
| Shield Coverage | 100 % | 100 % |
| Shield Material | Aluminum | Aluminum |
| Shield Type | Foil | Foil |
| Wire Gauge | 18 AWG | 18 AWG |
1095A Series
CABLE 36 COND 18AWG BLACK
| Part | Jacket Color | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Wire Gauge | Conductor Strand [custom] | Conductor Strand [custom] | Conductor Material | Conductor Insulation | Shield Coverage | Number of Conductors | Jacket (Insulation) Material | Cable Type | Shield Type | Features | Shield Material | Length [x] | Length [x] | Length | Length |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Belden Inc. 1095A 0105000 | Black | 2.108 mm | 0.083 in | 0.94 in | 23.88 mm | 18 AWG | 26 AWG | 7 | Copper, Bare | Nylon, Poly-Vinyl Chloride (PVC), Polyamide (PA) | 100 % | 36 | Poly-Vinyl Chloride (PVC) | Multi-Triad | Foil | Drain Wire, Rip Cord | Aluminum | ||||
Belden Inc. 1095A 0107500 | Black | 2.108 mm | 0.083 in | 0.94 in | 23.88 mm | 18 AWG | 26 AWG | 7 | Copper, Bare | Nylon, Poly-Vinyl Chloride (PVC), Polyamide (PA) | 100 % | 36 | Poly-Vinyl Chloride (PVC) | Multi-Triad | Foil | Drain Wire, Rip Cord | Aluminum | 7500 ft | 2286 m | ||
Belden Inc. 1095A 0102500 | Black | 2.108 mm | 0.083 in | 0.94 in | 23.88 mm | 18 AWG | 26 AWG | 7 | Copper, Bare | Nylon, Poly-Vinyl Chloride (PVC), Polyamide (PA) | 100 % | 36 | Poly-Vinyl Chloride (PVC) | Multi-Triad | Foil | Drain Wire, Rip Cord | Aluminum | 2500 ft | 762 m |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Spool | 5000 | $ 13.58 | |
Description
General part information
1095A Series
36 (12 Triad Twisted) Conductor Multi-Triad Cable Black 18 AWG Foil 5000' (1524.0m)
