DC0001/14-TG-A482K-0.1-0

Active

t-Global Technology

THERM PAD 45.21X31.75MM RED

Search across all available documentation for this part.

Active

t-Global Technology

THERM PAD 45.21X31.75MM RED

Technical Specifications

Parameters and characteristics commom to parts in this series

THERM PAD 45.21X31.75MM W/ADH

Part	Color	Adhesive	Usage	Outline [x]	Outline [y]	Thermal Conductivity	Shelf Life	Thickness [custom]	Thickness [custom]	Shape	Type	Backing, Carrier	Material	Thickness [x]	Thickness [x]	Shelf Life Start	Thickness	Thickness
t-Global Technology DC0001/14-TG-A373F-0.25-2A	Yellow	Adhesive - Both Sides	TO-3	45.21 mm	31.75 mm	1.4 W/m-K	12 Months	0.254 mm	0.01 in	Rhombus	Die-Cut Pad, Sheet
t-Global Technology DC0001/14-TI900-0.12-2A	White	Adhesive - Both Sides	TO-3	45.21 mm	31.75 mm	1.8 W/m-K	24 Months			Rhombus	Die-Cut Pad, Sheet	Viscose	Silicone	0.005 in	0.127 mm
t-Global Technology DC0001/14-TG-A486G-0.3-2A	Gray	Adhesive - Both Sides	TO-3	45.21 mm	31.75 mm	6 W/m-K	12 Months	0.305 mm	0.012 "	Rhombus	Die-Cut Pad, Sheet					Date of Purchase
t-Global Technology DC0001/14-TG-A482K-0.1-0	Red		TO-3	45.21 mm	31.75 mm	2.3 W/m-K	24 Months			Rhombus	Die-Cut Pad, Sheet		Silicone			Date of Purchase	0.1 mm	0.0039 in
t-Global Technology DC0001/14-TG-AH482-2.0-0	Red		TO-3	45.21 mm	31.75 mm	2.2 W/m-K	24 Months			Rhombus	Die-Cut Pad, Sheet						2 mm	0.079 in
