1713020
ActivePhoenix Contact
TERM BLOCK 4POS 45DEG 3.5MM PCB
1713020
ActivePhoenix Contact
TERM BLOCK 4POS 45DEG 3.5MM PCB
Description
General part information
1713020
4 Position Wire to Board Terminal Block 45° (135°) Angle with Board 0.138" (3.50mm) Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | 1713020 |
|---|---|
| Current | 2 A |
| Mating Orientation (Angle) | 45 ° |
| Mating Orientation (Angle) (Alternate) | 135 ° |
| Mating Orientation (Description) | Angle with Board |
| Mounting Type | Through Hole |
| Number of Levels | 1 |
| Pitch | 0.138 in |
| Positions Per Level | 4 |
| Wire Termination | Leg Spring, Screwless, Push-In Spring, Spring Cage, Tension Clamp |
