SLLC-ETD44-12
ActiveSignal Transformer
RESONANT XFMR ETD44 12V 250W
SLLC-ETD44-12
ActiveSignal Transformer
RESONANT XFMR ETD44 12V 250W
Description
General part information
SLLC-ETD44-12
LED Drivers, AC/DC SMPS For For AC/DC Converters SMPS Transformer 4000V Isolation 70 ~ 120kHz Through Hole
Technical Specifications
Parameters and characteristics for this part
| Specification | SLLC-ETD44-12 |
|---|---|
| Applications | LED Drivers, AC/DC SMPS |
| Frequency (Max) | 120 kHz |
| Frequency (Min) | 70 Hz |
| Height - Seated (Max) | 1.083 in |
| Inductance | 476 µH |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Size / Dimension Length | 1.89 in |
| Size / Dimension Width | 1.811 in |
| Style | Wirewound |
| Type | For AC/DC Converters |
| Voltage - Isolation | 4000 Vpk |
| Voltage - Primary (Max) | 400 V |
| Voltage - Primary (Min) | 360 V |
