XPN7R104NC,L1XHQ
ActiveToshiba Semiconductor and Storage
MOSFET N-CH 40V 20A 8TSON
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
XPN7R104NC,L1XHQ
ActiveToshiba Semiconductor and Storage
MOSFET N-CH 40V 20A 8TSON
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | XPN7R104NC,L1XHQ |
|---|---|
| Current - Continuous Drain (Id) @ 25°C | 20 A |
| Drain to Source Voltage (Vdss) | 40 V |
| Drive Voltage (Max Rds On, Min Rds On) | 10 V, 4.5 V |
| FET Type | N-Channel |
| Gate Charge (Qg) (Max) @ Vgs [Max] | 21 nC |
| Input Capacitance (Ciss) (Max) @ Vds [Max] | 1290 pF |
| Mounting Type | Surface Mount |
| Operating Temperature | 175 °C |
| Package / Case | 8-PowerVDFN |
| Power Dissipation (Max) | 840 mW, 65 W |
| Rds On (Max) @ Id, Vgs | 7.1 mOhm |
| Supplier Device Package | 8-TSON Advance-WF |
| Supplier Device Package [x] | 3.1 |
| Supplier Device Package [y] | 3.1 |
| Technology | MOSFET (Metal Oxide) |
| Vgs (Max) | 20 V |
| Vgs(th) (Max) @ Id | 2.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.75 | |
| 10 | $ 1.11 | |||
| 100 | $ 0.75 | |||
| 500 | $ 0.59 | |||
| 1000 | $ 0.54 | |||
| 2000 | $ 0.50 | |||
| Digi-Reel® | 1 | $ 1.75 | ||
| 10 | $ 1.11 | |||
| 100 | $ 0.75 | |||
| 500 | $ 0.59 | |||
| 1000 | $ 0.54 | |||
| 2000 | $ 0.50 | |||
| Tape & Reel (TR) | 5000 | $ 0.45 | ||
| 10000 | $ 0.45 | |||
Description
General part information
XPN7R104NC,L1XHQ
N-Channel 40 V 20A (Ta) 840mW (Ta), 65W (Tc) Surface Mount 8-TSON Advance-WF (3.1x3.1)
