Description
General part information
A6X30144579
470k Ohm 1 Gang Linear Panel Mount Potentiometer 1.0 Turns Screw Terminal, Pressure Plate
Technical Specifications
Parameters and characteristics for this part
| Specification | A6X30144579 |
|---|---|
| Actuator Diameter | 1.181 in |
| Actuator Type | Round |
| Adjustment Type | Top Adjustment |
| Built in Switch | None |
| Mounting Type | Panel Mount |
| Number of Gangs | 1 |
| Number of Turns | 1 turns |
| Resistance | 470 kOhm |
| Rotation | 280 ° |
| Size - Body Face Length | 1.575 in |
| Size - Body Face Width | 1.181 in |
| Size - Body Shape | Rectangular |
| Taper | Linear |
| Termination Style | Screw Terminal, Pressure Plate |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Sign in to see pricing
Create a free account to access distributor pricing data.
CAD
3D models and CAD resources for this part
Documents
Technical documentation and resources
