Part	Specifications	Shielding	Mounting Type	Connector Type	Ingress Protection Description	Ingress Protection IP Rating	Number of Ports	Operating Temperature (Min)	Operating Temperature (Max)	Termination	Number of Contacts	Mounting Feature	Gender	Mating Cycles	Current Rating	Shell/Shielding Material	Contact Finish	Material Flammability Rating	Insulation Color	Features	Convert From (Adapter End)	Convert To (Adapter End)	Convert To (Adapter End) Type	Convert To (Adapter End) Positions
Amphenol ICC (Commercial Products) MUSBAA11M0	USB 2.0	Shielded	Panel Mount	USB-A (USB TYPE-A)	Dust Tight Waterproof	IP67	1	-40 °C	105 °C	PC Board Solder	4	Flange Horizontal	Receptacle	1500 cycles	1.5 A	Copper Alloy	Gold	UL94 V-0	Black
Amphenol ICC (Commercial Products) MUSBA11131	USB 2.0	Shielded	Panel Mount Right Angle Through Hole	USB-A (USB TYPE-A)	Dust Tight Waterproof	IP67	1	-40 °C	105 °C	Solder	4	Flange Horizontal	Receptacle	1500 cycles	1.5 A	Copper Alloy	Gold	UL94 V-0	Black	Cover
Amphenol ICC (Commercial Products) MUSBA81130																					Receptacle USB-A (USB TYPE-A)	Receptacle USB-A (USB TYPE-A)
Amphenol ICC (Commercial Products) MUSBA51105	USB 2.0	Shielded	Panel Mount Through Hole	USB-A (USB TYPE-A)	Dust Tight Waterproof	IP67	1	-40 °C	105 °C	Solder	4	Flange Vertical	Receptacle	1500 cycles	1.5 A	Copper Alloy	Gold	UL94 V-0	Black	Board Lock Cover
Amphenol ICC (Commercial Products) MUSBA211M0			Board Mounted																		Receptacle USB-A (USB TYPE-A)		Male Pins Rectangular Connector	14 Pos
Amphenol ICC (Commercial Products) MUSBA31135			Board Mounted																		Receptacle USB-A (USB TYPE-A)	Receptacle USB-A (USB TYPE-A)
Amphenol ICC (Commercial Products) MUSBA21135			Board Mounted																		Receptacle USB-A (USB TYPE-A)		Male Pins Rectangular Connector	14 Pos
Amphenol ICC (Commercial Products) MUSBA411M0																					Receptacle USB-A (USB TYPE-A)	Terminal Blocks
Amphenol ICC (Commercial Products) MUSBA311M0			Board Mounted																		Receptacle USB-A (USB TYPE-A)	Receptacle USB-A (USB TYPE-A)
Amphenol ICC (Commercial Products) MUSBA211M1			Board Mounted																		Receptacle USB-A (USB TYPE-A)		Male Pins Rectangular Connector	14 Pos

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

Datasheet
