VDRS10P385TME
ActiveVishay Dale
VARISTOR 620V 2.5KA DISC 12.50MM
VDRS10P385TME
ActiveVishay Dale
VARISTOR 620V 2.5KA DISC 12.50MM
Description
General part information
VDRS10P385TME
620 V 2.5 kA Varistor 1 Circuit Through Hole Disc 12.50mm
Technical Specifications
Parameters and characteristics for this part
| Specification | VDRS10P385TME |
|---|---|
| Capacitance | 180 pF |
| Current - Surge | 2500 A |
| Energy | 67 J |
| Maximum AC Volts | 385 V |
| Maximum DC Voltage | 505 V |
| Mounting Type | Through Hole |
| Number of Circuits | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package Diameter | 12.5 mm |
| Package Name | Disc |
| Varistor Voltage (Max) | 682 V |
| Varistor Voltage (Min) | 558 V |
| Varistor Voltage (Typ) | 620 V |
