Description
General part information
SWM12 Series
Wall Mount AC Adapters 12W 6V 2A EU Vert 2.1plug
Technical Specifications
Parameters and characteristics for this part
| Specification | SWM12-6-NH-P6R |
|---|---|
| Applications | Medical |
| Approval Agency | CB Scheme, UL, PSE, FCC, IEC, CSA, EN |
| Cord Length | 59 in |
| Current - Output (Max) | 2 A |
| Efficiency | Level VI, CoC Tier 2 |
| Form | Wall Mount (Class II) |
| Input Connector | NEMA 1-15P |
| Input Type | Fixed Blade |
| No Load Power Consumption (Max) | 100 mW |
| Operating Temperature (Max) | 40 °C |
| Operating Temperature (Min) | 0 °C |
| Output Connector | Barrel Plug R/A |
| Output Connector I.D. | 2.5 mm |
| Output Connector Length | 9.5 mm |
| Output Connector O.D. | 5.5 mm |
| Polarization | Positive Center |
| Power (Watts) | 12 W |
| Region Utilized | North America |
| Size / Dimension Height | 1.44 in |
| Size / Dimension Length | 2.17 in |
| Size / Dimension Width | 0.98 in |
| Standard Number | 60601-1, 60950-1, 55032 Class B, 55024, 61000-3-2, 61000-3-3, C22.2 No. 60601-1 |
| Voltage - Input (AC) Maximum | 264 V |
| Voltage - Input (AC) Minimum | 90 V |
| Voltage - Output | 6 V |
