0122M4-16.000F10DZNJK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
CRYSTAL, 2520, 4PADS, 16MHZ, 10P
0122M4-16.000F10DZNJK
ActiveSuzhou Hangjing Elec&Tech Co.,Ltd
CRYSTAL, 2520, 4PADS, 16MHZ, 10P
Description
General part information
0122M4-16.000F10DZNJK
Crystal
Technical Specifications
Parameters and characteristics for this part
| Specification | 0122M4-16.000F10DZNJK |
|---|---|
| ESR (Equivalent Series Resistance) | 100 Ohm, 70 Ohm |
| Frequency | 16 MHz |
| Frequency Stability | 30 ppm |
| Frequency Tolerance | 10 ppm |
| Height - Seated (Max) | 0.022 in, 0.024 in |
| Load Capacitance | 16 pF |
| Mounting Type | Surface Mount |
| Operating Mode | Fundamental |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension Length | 0.098 in |
| Size / Dimension Width | 0.079 in |
| Type | MHz Crystal |
