TPC1133GLFG
ObsoleteLITTELFUSE
SWITCH THUMBWHEEL DGTL 50MA 32V
TPC1133GLFG
ObsoleteLITTELFUSE
SWITCH THUMBWHEEL DGTL 50MA 32V
Description
General part information
TPC1133GLFG
Thumbwheel, 1 - Axis Digital (Mechanical Switch) Output
Technical Specifications
Parameters and characteristics for this part
| Specification | TPC1133GLFG |
|---|---|
| Actuator Type | Thumbwheel |
| Axis Count | 1 Axis |
| Contact Finish | Gold |
| Current Rating | 50 mA |
| Mounting Type | Surface Mount |
| Operating Force (Max) | 220 gf |
| Operating Force (Min) | 100 gf |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Output | Digital (Mechanical Switch) |
| Switch Function | 2-Way Directional, Center Select |
| Termination Style | Gull Wing |
| Type | 1 - Axis, Thumbwheel |
| Voltage Rating - DC | 32 V |
