MAXQ2000-KIT
ActiveAnalog Devices Inc./Maxim Integrated
MAXQ2000 EVAL BRD
Deep-Dive with AI
Search across all available documentation for this part.
MAXQ2000-KIT
ActiveAnalog Devices Inc./Maxim Integrated
MAXQ2000 EVAL BRD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAXQ2000-KIT | MAXQ2000 Series |
|---|---|---|
| Board Type | Evaluation Platform | Evaluation Platform |
| Connectivity | - | 1-Wire®, SPI, UART/USART |
| Contents | LCD, Board(s), Cable(s) | LCD, Board(s), Cable(s) |
| Core Processor | MAXQ20 | MAXQ20 |
| Core Size | - | 16-Bit |
| Mounting Type | Fixed | Surface Mount, Fixed |
| Number of I/O | - | 50 I/O |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Oscillator Type | - | Internal |
| Package / Case | - | 56-WFQFN Exposed Pad, 68-VFQFN Exposed Pad, 100-LQFP |
| Peripherals | - | LCD, POR, PWM, WDT |
| Program Memory Size | - | 64 KB |
| Program Memory Type | - | FLASH |
| RAM Size | - | 2K x 8 |
| Speed | - | 20 MHz |
| Supplier Device Package | - | 56-TQFN (8x8), 68-QFN (10x10), 100-LQFP (14x14) |
| Type | MCU 16-Bit | MCU 16-Bit |
| Utilized IC / Part | MAXQ2000 | MAXQ2000 |
| Voltage - Supply (Vcc/Vdd) | - | 1.8 V |
| Voltage - Supply (Vcc/Vdd) | - | 2.75 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
MAXQ2000 Series
IC MCU 16BIT 64KB FLASH 56TQFN
| Part | Core Size | Connectivity | RAM Size | Program Memory Type | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Oscillator Type | Voltage - Supply (Vcc/Vdd) [Min] | Voltage - Supply (Vcc/Vdd) [Max] | Number of I/O | Program Memory Size | Peripherals | Supplier Device Package | Speed | Board Type | Core Processor | Utilized IC / Part | Contents | Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAXQ2000-QBX+ | 16-Bit | 1-Wire®, SPI, UART/USART | 2K x 8 | FLASH | 56-WFQFN Exposed Pad | 85 °C | -40 °C | Surface Mount | Internal | 1.8 V | 2.75 V | 50 I/O | 64 KB | LCD, POR, PWM, WDT | 56-TQFN (8x8) | 20 MHz | |||||
Analog Devices Inc./Maxim Integrated MAXQ2000-QBX | 16-Bit | 1-Wire®, SPI, UART/USART | 2K x 8 | FLASH | 56-WFQFN Exposed Pad | 85 °C | -40 °C | Surface Mount | Internal | 1.8 V | 2.75 V | 50 I/O | 64 KB | LCD, POR, PWM, WDT | 56-TQFN (8x8) | 20 MHz | |||||
Analog Devices Inc./Maxim Integrated MAXQ2000-KIT | Fixed | Evaluation Platform | MAXQ20 | MAXQ2000 | Board(s), Cable(s), LCD | MCU 16-Bit | |||||||||||||||
Analog Devices Inc./Maxim Integrated MAXQ2000-RAX+ | 16-Bit | 1-Wire®, SPI, UART/USART | 2K x 8 | FLASH | 68-VFQFN Exposed Pad | 85 °C | -40 °C | Surface Mount | Internal | 1.8 V | 2.75 V | 50 I/O | 64 KB | LCD, POR, PWM, WDT | 68-QFN (10x10) | 20 MHz | |||||
Analog Devices Inc./Maxim Integrated MAXQ2000-QAX+ | 16-Bit | 1-Wire®, SPI, UART/USART | 2K x 8 | FLASH | 68-VFQFN Exposed Pad | 85 °C | -40 °C | Surface Mount | Internal | 1.8 V | 2.75 V | 50 I/O | 64 KB | LCD, POR, PWM, WDT | 68-QFN (10x10) | 20 MHz | |||||
Analog Devices Inc./Maxim Integrated MAXQ2000-RBX+ | 16-Bit | 1-Wire®, SPI, UART/USART | 2K x 8 | FLASH | 56-WFQFN Exposed Pad | 85 °C | -40 °C | Surface Mount | Internal | 1.8 V | 2.75 V | 50 I/O | 64 KB | LCD, POR, PWM, WDT | 56-TQFN (8x8) | 20 MHz | |||||
Analog Devices Inc./Maxim Integrated MAXQ2000-RFX+ | 16-Bit | 1-Wire®, SPI, UART/USART | 2K x 8 | FLASH | 100-LQFP | 85 °C | -40 °C | Surface Mount | Internal | 1.8 V | 2.75 V | 50 I/O | 64 KB | LCD, POR, PWM, WDT | 100-LQFP (14x14) | 20 MHz |
Description
General part information
MAXQ2000 Series
MAXQ2000 MAXQ® MAXQ20 MCU 16-Bit Embedded Evaluation Board
