RE77-S-S-L
ActiveRishabh Instruments
TEMP CONTROLLR 20-60VDC/20-40VAC
RE77-S-S-L
ActiveRishabh Instruments
TEMP CONTROLLR 20-60VDC/20-40VAC
Description
General part information
RE77-S-S-L
Temperature Controller (RTD, Type B, E, J, K, N, R, S, T) 20 ~ 40VAC, 20 ~ 60VDC DIN Rail
Technical Specifications
Parameters and characteristics for this part
| Specification | RE77-S-S-L |
|---|---|
| Control Method | Off, Proportional (PID), On |
| Display Type | LCD - Dual Color Characters |
| Ingress Protection Description | Water Resistant, Dust Protected |
| Ingress Protection IP Rating | IP54 |
| Input Temperature (Max) | 1767 °C |
| Input Temperature (Min) | -200 °C |
| Maximum Number of Characters Per Row | 4 characters |
| Minimum Number of Characters Per Row | 4 characters |
| Mounting Type | DIN Rail |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | -20 °C |
| Output Type | Solid State (2) |
| Panel Cutout Length | 92.6 mm |
| Panel Cutout Shape | Square |
| Panel Cutout Width | 45.6 mm |
| Termination Style | Screw Terminal |
| Type | E, T), S, J, R, Temperature Controller (RTD, Type B, N, K |
| Voltage - Supply (Range 1 Maximum) | 40 VAC |
| Voltage - Supply (Range 1 Minimum) | 20 VAC |
| Voltage - Supply (Range 2 Maximum) | 60 VDC |
| Voltage - Supply (Range 2 Minimum) | 20 VDC |
