83321E 0091000

Active

Belden Inc.

CABLE 2COND 18AWG WHT SHLD

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 2COND 18AWG WHT SHLD

Technical Specifications

Parameters and characteristics for this part

Specification	83321E 0091000

Cable Type	Multi-Conductor
Conductor Insulation	Tetrafluoroethylene (TFE)
Conductor Material	Copper, Silver Coated
Conductor Strand [custom]	19
Conductor Strand [custom]	30 AWG
Jacket (Insulation) Diameter [diameter]	0.179 in
Jacket (Insulation) Diameter [diameter]	4.55 mm
Jacket (Insulation) Material	Tetrafluoroethylene (TFE)
Jacket (Insulation) Thickness	0.279 mm
Jacket (Insulation) Thickness	0.011 in
Length	1000 ft
Length	304.8 m
Number of Conductors	2
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-65 ░C
Shield Coverage	85 %
Shield Material	Copper, Silver Coated
Shield Type	Braid
Wire Gauge	18 AWG

Part	Conductor Material	Jacket (Insulation) Material	Shield Material	Conductor Strand [custom]	Conductor Strand [custom]	Number of Conductors	Wire Gauge	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Shield Type	Operating Temperature [Min]	Operating Temperature [Max]	Length [x]	Length [x]	Shield Coverage	Cable Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Conductor Insulation	Length	Length
Belden Inc. 83321E 009100	Copper Silver Coated	Tetrafluoroethylene (TFE)	Copper Silver Coated	19	30 AWG	2	18 AWG	0.179 in	4.55 mm	Braid	-65 ░C	200 °C	30.5 m	100 ft	85 %	Multi-Conductor	0.279 mm	0.011 in	Tetrafluoroethylene (TFE)
Belden Inc. 83321E 0091000	Copper Silver Coated	Tetrafluoroethylene (TFE)	Copper Silver Coated	19	30 AWG	2	18 AWG	0.179 in	4.55 mm	Braid	-65 ░C	200 °C			85 %	Multi-Conductor	0.279 mm	0.011 in	Tetrafluoroethylene (TFE)	1000 ft	304.8 m
Belden Inc. 83321E 009500	Copper Silver Coated	Tetrafluoroethylene (TFE)	Copper Silver Coated	19	30 AWG	2	18 AWG	0.179 in	4.55 mm	Braid	-65 ░C	200 °C	152.4 m	500 '	85 %	Multi-Conductor	0.279 mm	0.011 in	Tetrafluoroethylene (TFE)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	1000	$ 12.37

General part information

2 (1 Pair) Conductor Multi-Conductor Cable White 18 AWG Braid 1000.0' (304.8m)
