PXEB5423B005
ActiveFIBER OPTIC CABLE, MULTIMODE, 4 FIBERS, 62.5ΜM / 125ΜM, SC TO FREE END, 16.4 FT
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PXEB5423B005 |
|---|---|
| 1st Connector | SC (4) |
| Bend Radius [radius] | 22 mm |
| Cable Diameter [diameter] | 0.23 in |
| Cable Diameter [diameter] | 5.9 mm |
| Cable Type | Buffered Fiber |
| Color - Cable | Black |
| Color - Connectors | Black, Aqua |
| Fiber Type | 62.5/125 |
| Insertion Loss | 2 dB |
| Jacket (Insulation) Material | Polyurethane (PUR) |
| Length - Overall | 5 m |
| Length - Overall | 16.4 ft |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -50 °C |
| Type | Multimode, OM1 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 5 | $ 879.56 | |
Description
General part information
PXEB5423B005
5000 series expanded beam connector range provides a high performance and a simple termination process. This allows for a rapid in-field termination and repair where inserts and termination kits are available. Moreover, the newly designed cable management system prevents fibers and cable to be twisted and their corresponding performance loss. The maximum insertion loss is <lt/>2dB and average insertion loss is <lt/>1.5dB. All plastic body version; UL94-V0 rated, UV stable, halogen free, light-weight, self-extinguishing material suitable for long-term outdoor and defense use.
