Description
General part information
TB6-5020D3DH
Three Phase (Delta) EMC/EMI Line Filter 20 A 50 ~ 60Hz Two Stage Terminal Block
Technical Specifications
Parameters and characteristics for this part
| Specification | TB6-5020D3DH |
|---|---|
| Applications | General Purpose |
| Approval Agency | ENEC, SEMKO, UR, UL, CE |
| Configuration | Two Stage |
| Current | 20 A |
| Filter Subtype | Delta |
| Filter Type | Three Phase |
| Frequency - Operating (Max) | 60 Hz |
| Frequency - Operating (Min) | 50 Hz |
| Mounting Type | Chassis Mount |
| Termination Style | Terminal Block |
| Voltage - Rated AC (Phase to Ground/Neutral) | 290 V |
| Voltage - Rated AC (Phase to Phase) | 500 V |
