Specification	FFSD-13-D-18.50-01-N-D04-R

Cable Termination	IDC
Color	Gray, Ribbon
Connector Pin Count	3 Pin
Connector Type	Socket to Socket
Contact Finish	Gold
Contact Finish Thickness	10 Ąin
Features	Polarizing Key, Reverse Wiring
Length	1.54 ft
Number of Positions	26
Number of Rows	2
Pitch - Cable	0.025 in
Pitch - Connector	0.05 in
Shielding	Unshielded

FFSD Series

...

Part	Color	Number of Rows	Pitch - Cable	Pitch - Connector	Cable Termination	Connector Type	Contact Finish Thickness	Number of Positions	Length	Shielding	Features	Contact Finish
Samtec Inc. FFSD-13-D-72.00-01-N	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Socket	10 Ąin	26	6 ft	Unshielded	Polarizing Key	Gold
Samtec Inc. FFSD-20-D-02.76-01-N-RN1	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Socket	10 Ąin	40	0.23 ft	Unshielded	Polarizing Key	Gold
Samtec Inc. FFSD-15-S-28.00-01-N	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Cable	10 Ąin	30	2.33 ft	Unshielded	Polarizing Key	Gold
Samtec Inc. FFSD-17-D-42.00-01-N	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Socket	10 Ąin	34	3.5 ft	Unshielded	Polarizing Key	Gold
Samtec Inc. FFSD-20-D-06.80-01-N	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Socket	10 Ąin	40	0.567 ft	Unshielded	Polarizing Key	Gold
Samtec Inc. FFSD-08-D-07.75-01-N	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Socket	10 Ąin	16	0.646 ft	Unshielded	Polarizing Key	Gold
Samtec Inc. FFSD-17-D-02.16-01-N	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Socket	10 Ąin	34	0.18 ft	Unshielded	Polarizing Key	Gold
Samtec Inc. FFSD-06-D-06.00-01-N	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Socket	10 Ąin	12	0.5 ft	Unshielded	Polarizing Key	Gold
Samtec Inc. FFSD-10-D-20.50-01-N-R	Gray Ribbon	2	0.025 in	0.05 in	IDC	Reversed Socket to Socket	10 Ąin	20	1.71 ft	Unshielded	Polarizing Key Reverse Wiring	Gold
Samtec Inc. FFSD-03-S-36.00-01-RW	Gray Ribbon	2	0.025 in	0.05 in	IDC	Socket to Cable	10 Ąin	6	3 ft	Unshielded	Reverse Wiring	Gold
