PCHC25-R18M-RC
ActiveAllied Components International
.18UH 20% PWR CHIP HIGH CURRENT
PCHC25-R18M-RC
ActiveAllied Components International
.18UH 20% PWR CHIP HIGH CURRENT
Description
General part information
PCHC25-R18M-RC
180 nH Unshielded Wirewound Inductor Nonstandard
Technical Specifications
Parameters and characteristics for this part
| Specification | PCHC25-R18M-RC |
|---|---|
| Height - Seated (Max) | 0.197 in |
| Inductance | 180 nH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature (Max) | 125 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Unshielded |
| Size / Dimension Length | 0.35 in |
| Size / Dimension Width | 0.24 in |
| Tolerance | 20 % |
| Type | Wirewound |
