Description
General part information
P7805-2000R-S
Non-Isolated PoL Module DC DC Converter 1 Output 5V 2A 8V - 36V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | P7805-2000R-S |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 2 A |
| Efficiency | 92 % |
| Mounting Type | Through Hole, Right Angle |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Package / Case | 3-SIP Module |
| Power (Watts) | 10 W |
| Size / Dimension Height | 0.35 in |
| Size / Dimension Length | 0.69 in |
| Size / Dimension Width | 0.45 in |
| Standard Number | 62368-1 |
| Type | Non-Isolated PoL Module |
| Voltage - Input (Max) | 36 V |
| Voltage - Input (Min) | 8 V |
| Voltage - Output 1 | 5 V |
