CPCI-A-3U-300C
ActiveMurata Power Solutions Inc.
AC/DC CNVRTR 5V 3.3V +/-12V 300W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CPCI-A-3U-300C
ActiveMurata Power Solutions Inc.
AC/DC CNVRTR 5V 3.3V +/-12V 300W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CPCI-A-3U-300C |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE |
| Current - Output 1 | 30 A |
| Current - Output 2 | 40 A |
| Current - Output 3 | 5 A |
| Current - Output 4 | 500 mA |
| Efficiency | 81 % |
| Features | PFC, Hot Swappable, Universal Input |
| Mounting Type | Compact PCI® |
| Number of Outputs | 4 |
| Operating Temperature [Max] | 50 °C |
| Operating Temperature [Min] | -5 °C |
| Power (Watts) | 300 W |
| Size / Dimension [x] | 169.6 mm |
| Size / Dimension [x] | 6.68 " |
| Size / Dimension [y] | 1.59 " |
| Size / Dimension [y] | 40.3 mm |
| Size / Dimension [z] | 128.6 mm |
| Size / Dimension [z] | 5.06 " |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 5 V |
| Voltage - Output 2 | 3.3 V |
| Voltage - Output 3 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
CPCI-A Series
AC/DC CNVRTR 5V 3.3V +/-12V 300W
| Part | Efficiency | Voltage - Output 3 | Number of Outputs | Approval Agency | Current - Output 3 | Applications | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input [Min] | Voltage - Input [Max] | Current - Output 4 | Voltage - Output 1 | Mounting Type | Type | Voltage - Isolation | Features | Current - Output 1 | Voltage - Output 2 | Current - Output 2 | Power (Watts) | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Murata Power Solutions Inc. CPCI-A-3U-300C | 81 % | 12 V | 4 | CE | 5 A | ITE (Commercial) | 50 °C | -5 °C | 90 VAC | 264 VAC | 500 mA | 5 V | Compact PCI® | Enclosed | 3000 V | Hot Swappable, PFC, Universal Input | 30 A | 3.3 V | 40 A | 300 W | 169.6 mm | 128.6 mm | 1.59 " | 5.06 " | 40.3 mm | 6.68 " |
Description
General part information
CPCI-A Series
Enclosed AC DC Converters 4 Output 5V 3.3V 12V -12V 90 ~ 264 VAC Input
