Specification	MIC5239-5.0BM

Control Features	Enable
Current - Output	500 mA
Current - Quiescent (Iq)	45 µA
Current - Supply (Max)	15 mA
Mounting Type	Surface Mount
Number of Regulators	1
Operating Temperature (Max)	125 °C
Operating Temperature (Min)	-40 °C
Output Configuration	Positive
Output Type	Fixed
Package Length	0.154 in
Package Name	8-SOIC
Package Width	3.9 mm
Protection Features	Reverse Polarity, Over Voltage, Over Current, Over Temperature
Voltage - Input (Max)	30 V p-p
Voltage - Output (Min/Fixed)	5 V
Voltage Dropout (Typical)	0.35 V

MIC5239 Series

...

Part	Output Type	Protection Features	Mounting Type	Output Configuration	Current - Supply (Max)	Operating Temperature (Max)	Operating Temperature (Min)	Current - Output	Voltage - Output (Min/Fixed)	Package Width	Package Name	Package Length	Voltage Dropout (Typical)	Number of Regulators	Current - Quiescent (Iq)	Voltage - Input (Max)	Control Features	Package / Case
Microchip Technology MIC5239-3.3BMM-TR	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	3.3 V	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	0.35 V	1	45 µA	30 V p-p	Enable
Microchip Technology MIC5239-3.3BMM	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	3.3 V	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	0.35 V	1	45 µA	30 V p-p	Enable
Microchip Technology MIC5239-3.3YM	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	3.3 V	3.9 mm	8-SOIC	0.154 in	0.35 V	1	45 µA	30 V p-p	Enable
Microchip Technology MIC5239-3.15BMM-TR	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	3.15 V	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	0.35 V	1	45 µA	30 V p-p	Enable
Microchip Technology MIC5239-1.8YS	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	1.8 V		SOT-223-3		0.35 V	1	45 µA	30 V p-p	Enable	TO-261-4 TO-261AA
Microchip Technology MIC5239-5.0YMM	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	5 V	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	0.35 V	1	45 µA	30 V p-p	Enable
Microchip Technology MIC5239-3.15BS TR	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	3.15 V		SOT-223-3		0.35 V	1	45 µA	30 V p-p	Enable	TO-261-4 TO-261AA
Microchip Technology MIC5239-5.0YM-TR	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	5 V	3.9 mm	8-SOIC	0.154 in	0.35 V	1	45 µA	30 V p-p	Enable
Microchip Technology MIC5239-1.5BMM	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	1.5 V	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	0.35 V	1	45 µA	30 V p-p	Enable
Microchip Technology MIC5239-2.5YMM	Fixed	Over Current Over Temperature Over Voltage Reverse Polarity	Surface Mount	Positive	15 mA	125 °C	-40 °C	500 mA	2.5 V	3 mm	8-MSOP 8-TSSOP 8-MSOP	0.118 in	0.35 V	1	45 µA	30 V p-p	Enable

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

MIC5239-5.0BM | Datasheet
