Specification	1708757

Color	Gray
Current - UL	200 A
Front Panel Wire Connection (Method)	Push In Clamp
Number of Levels	1
Panel Mount Count	2 Piece
Panel Mount Type	2 Piece
Panel Thickness (Max)	0.197 in
Panel Thickness (Min)	0.039 in
Pitch	0.984 in
Positions Per Level	6
Rear Panel Wire Connection	Bolt, Screw Clamp
Rear Panel Wire Connection (Wire Entry) Angle	90 °
Voltage - UL	600 V
Width	6.89 in
Wire Entry Angle (to Panel)	90 °
Wire Gauge	3/0-4 AWG
