FX2RLUNUNONM008
ObsoletePanduit Corp
FIBER OPTIC CABLE ASSEMBLIES OM3 2F 2MM PC LSZH LC UNIBOOT /LC UNIBOOT STD POLARITY OPT IL 8M
FX2RLUNUNONM008
ObsoletePanduit Corp
FIBER OPTIC CABLE ASSEMBLIES OM3 2F 2MM PC LSZH LC UNIBOOT /LC UNIBOOT STD POLARITY OPT IL 8M
Description
General part information
FX2RLUNUNONM008
Cable Fiber Optic LC Duplex To LC Duplex 50/125 26.2' (8.0m)
Technical Specifications
Parameters and characteristics for this part
| Specification | FX2RLUNUNONM008 |
|---|---|
| 1st Connector | LC Duplex |
| 2nd Connector | LC Duplex |
| Bend Radius | 40 mm |
| Cable Diameter | 0.08 " |
| Color - Cable | Aqua |
| Color - Connectors | Blue, Black |
| Fiber Cladding Diameter | 125 µm |
| Fiber Core Diameter | 50 µm |
| Insertion Loss | 0.15 dB |
| Jacket (Insulation) Material | Low Smoke Zero Halogen (LSZH) |
| Length - Overall | 26.2 ft |
| Operating Temperature (Max) | 60 °C |
| Operating Temperature (Min) | -10 °C |
| Return Loss | 0.26 dB |
| Type | Multimode, Duplex, OM3 |
