Description
General part information
CS3FR030E
30 mOhms ±1% 3W Through Hole Resistor 4-SIP Current Sense, Moisture Resistant, Non-Inductive Metal Element
Technical Specifications
Parameters and characteristics for this part
| Specification | CS3FR030E |
|---|---|
| Composition | Metal Element |
| Features | Moisture Resistant, Non-Inductive, Current Sense |
| Height - Seated (Max) | 0.78 in, 0.654 in |
| Number of Terminations | 4 |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package / Case | 4-SIP |
| Package Name | 4-SIP |
| Power (Watts) | 3 W |
| Resistance | 0.03 Ohms |
| Size / Dimension Length | 0.854 in |
| Size / Dimension Width | 0.211 in |
| Temperature Coefficient | 60 ppm/°C |
| Tolerance | 1 % |
