AHV12V25KV1MAW
ActiveAnalog Technologies, Inc.
HV 12V TO 25KV 25W DC-DC CONVERT
AHV12V25KV1MAW
ActiveAnalog Technologies, Inc.
HV 12V TO 25KV 25W DC-DC CONVERT
Description
General part information
AHV12V25KV1MAW
Enclosed DC DC Converter 1 Output 0 ~ 25000V 1mA 13V Input
Technical Specifications
Parameters and characteristics for this part
| Specification | AHV12V25KV1MAW |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 1 mA |
| Efficiency | 70 % |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature (Max) | 55 °C |
| Operating Temperature (Min) | -10 °C |
| Power (Watts) | 25 W |
| Size / Dimension Height | 2.17 in |
| Size / Dimension Length | 5.51 in |
| Size / Dimension Width | 3.94 in |
| Type | Enclosed |
| Voltage - Input (Max) | 13 V |
| Voltage - Input (Min) | 11 V |
| Voltage - Output 1 (Max) | 25000 V |
| Voltage - Output 1 (Min) | 0 V |
