ZMID52013AE1T
ActiveRenesas Electronics Corporation
SENSOR ROTARY 360DEG SMD
Deep-Dive with AI
Search across all available documentation for this part.
ZMID52013AE1T
ActiveRenesas Electronics Corporation
SENSOR ROTARY 360DEG SMD
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | ZMID52013AE1T |
|---|---|
| Actuator Type | Inductive Target |
| For Measuring | Rotary Position, Linear |
| Mounting Type | Surface Mount |
| Output | Analog Voltage |
| Output Signal | Clockwise Increase |
| Package / Case | 14-TSSOP |
| Package / Case [custom] | 0.173 " |
| Package / Case [custom] | 4.4 mm |
| Rotation Angle - Electrical, Mechanical [Max] | 360 ° |
| Rotation Angle - Electrical, Mechanical [Min] | 0 ° |
| Supplier Device Package | 14-TSSOP |
| Technology | Inductive |
| Termination Style | Gull Wing |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
ZMID52013 Series
SENSOR ROTARY 360DEG SMD
| Part | Voltage - Supply [Min] | Voltage - Supply [Max] | Mounting Type | Technology | Rotation Angle - Electrical, Mechanical [Max] | Rotation Angle - Electrical, Mechanical [Min] | Supplier Device Package | Termination Style | Actuator Type | For Measuring | Output Signal | Output | Package / Case [custom] | Package / Case [custom] | Package / Case |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Renesas Electronics Corporation ZMID52013AE1T | 4.5 V | 5.5 V | Surface Mount | Inductive | 360 ° | 0 ° | 14-TSSOP | Gull Wing | Inductive Target | Linear, Rotary Position | Clockwise Increase | Analog Voltage | 0.173 " | 4.4 mm | 14-TSSOP |
Description
General part information
ZMID52013 Series
Inductive Sensor Linear, Rotary Position Inductive Target Gull Wing
