Specification	5590H-05SQ-0.36(100)

Adhesive	Tacky - Both Sides
Color	Gray
Material	Acrylic Elastomer
Outline Diameter	9.14 mm
Shape	Round
Shelf Life	24 Months
Shelf Life Start	Date of Manufacture
Storage/Refrigeration Temperature (Maximum)	77 °F
Storage/Refrigeration Temperature (Minimum)	68 °F
Thermal Resistivity	0.46 °C/W
Thickness	0.0197 in
Type	Sheet, Interface Pad
Usage	TO-5

5590H Series

Part	Storage/Refrigeration Temperature (Minimum)	Storage/Refrigeration Temperature (Maximum)	Shelf Life Start	Shelf Life	Outline Width	Outline Length	Type	Material	Shape	Color	Adhesive	Thermal Resistivity	Thickness
3M (TC) 3M 5590H 0.75" X 20M	68 °F	77 °F	Date of Manufacture	24 Months	19.05 mm	20 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
3M (TC) 5590H-05-10-20	68 °F	77 °F	Date of Manufacture	24 Months	254 mm	20 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
3M (TC) 3M 5590H 0.5" X 20M	68 °F	77 °F	Date of Manufacture	24 Months	12.7 mm	20 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
3M (TC) 3M 5590H 7" X 20M	68 °F	77 °F	Date of Manufacture	24 Months	177.8 mm	20 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
3M (TC) 3M 5590H-05 SQUARE-30MM-100	68 °F	77 °F	Date of Manufacture	24 Months	30 mm	30 mm	Interface Pad Sheet	Acrylic Elastomer	Square	Gray	Tacky - Both Sides	0.46 °C/W	0.0197 in
3M (TC) 3M 5590H 3" X 20M	68 °F	77 °F	Date of Manufacture	24 Months	76.2 mm	20 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
3M (TC) 3M 5590H 4MMSQ-100	68 °F	77 °F	Date of Manufacture	24 Months	4 mm	100 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
3M (TC) 5590H-05CIR-5(100)	68 °F	77 °F	Date of Manufacture	24 Months	5 mm	100 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
3M (TC) 5590H08-0.375-20	68 °F	77 °F	Date of Manufacture	24 Months	9.53 mm	20 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
3M (TC) 3M 5590H 4.5MMSQ-100	68 °F	77 °F	Date of Manufacture	24 Months	4.5 mm	100 m	Interface Pad Roll	Acrylic Elastomer	Rectangular	Gray White	Tacky - Both Sides
