Specification	EDH228M010S9RAA

Applications	Automotive
Capacitance	2200 ĄF
Height - Seated (Max)	0.551 in
Lifetime	2000 Hrs
Mounting Type	Surface Mount
Operating Temperature (Max)	105 °C
Operating Temperature (Min)	-40 °C
Package / Case	Radial, Can - SMD
Polarization	Polar
Ratings	AEC-Q200
Ripple Current	680 mA, 850 mA
Size / Dimension Diameter	0.492 in
Surface Mount Land Length	0.504 in
Surface Mount Land Width	0.504 in
Tolerance	20 %
Voltage - Rated	10 V

EDH Series

Part	Polarization	Voltage - Rated	Size / Dimension Diameter	Tolerance	Capacitance	Surface Mount Land Length	Surface Mount Land Width	Applications	Lifetime	Height - Seated (Max)	Ripple Current	Mounting Type	Package / Case	Operating Temperature (Min)	Operating Temperature (Max)	Ratings
KEMET EDH107M063A9PAA	Polar	63 V	0.394 in	20 %	100 µF	0.406 in	0.406 in	General Purpose	2000 Hrs	0.413 in	340 mA 425 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C
KEMET EDH107M025A9MAA	Polar	25 VAC	0.315 in	20 %	100 µF	0.327 in	0.327 in	General Purpose	2000 Hrs	0.413 in	230 mA 287.5 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C
KEMET EDH107M6R3A9GAA	Polar	6.3 V	0.248 in	20 %	100 µF	0.26 in	0.26 in	General Purpose	2000 Hrs	0.222 in	71 mA 88.75 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C
KEMET EDH107M025S9HAA	Polar	25 VAC	0.248 in	20 %	100 µF	0.26 in	0.26 in	Automotive	2000 Hrs	0.315 in	100 mA 125 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C	AEC-Q200
KEMET EDH107M063S9PAA	Polar	63 V	0.394 in	20 %	100 µF	0.406 in	0.406 in	Automotive	2000 Hrs	0.413 in	340 mA 425 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C	AEC-Q200
KEMET EDH107M6R3S9GAA	Polar	6.3 V	0.248 in	20 %	100 µF	0.26 in	0.26 in	Automotive	2000 Hrs	0.222 in	71 mA 88.75 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C	AEC-Q200
KEMET EDH107M160S9TAA	Polar	160 V	0.63 in	20 %	100 µF	0.642 in	0.642 in	Automotive	2000 Hrs	0.689 in	250 mA 312.5 mA	Surface Mount	Can - SMD Radial	-25 °C	105 °C	AEC-Q200
KEMET EDH107M050A9MAA	Polar	50 V	0.315 in	20 %	100 µF	0.327 in	0.327 in	General Purpose	2000 Hrs	0.413 in	240 mA 300 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C
KEMET EDH107M025A9HAA	Polar	25 VAC	0.248 in	20 %	100 µF	0.26 in	0.26 in	General Purpose	2000 Hrs	0.315 in	100 mA 125 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C
KEMET EDH107M016A9HAA	Polar	16 V	0.248 in	20 %	100 µF	0.26 in	0.26 in	General Purpose	2000 Hrs	0.315 in	130 mA 162.5 mA	Surface Mount	Can - SMD Radial	-40 °C	105 °C

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Create a free account to access distributor pricing data.

CAD

3D models and CAD resources for this part

Documents

Technical documentation and resources

EDH-series.pdf

EDH228M010S9RAA | Datasheet

Datasheet

EDH228M010S9RAA
