603R25KL.25
ActiveSensata-BEI Sensors
SENSOR POSITION SPRING RET
Deep-Dive with AI
Search across all available documentation for this part.
603R25KL.25
ActiveSensata-BEI Sensors
SENSOR POSITION SPRING RET
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 603R25KL.25 |
|---|---|
| Actuator Type | Shaft |
| For Measuring | Linear Position |
| Linear Range [Max] | 3 in |
| Linear Range [Max] | 76.2 mm |
| Linear Range [Min] | 0 mm |
| Linear Range [Min] | 0 in |
| Linearity | 0.25 % |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -55 °C |
| Output | Resistive |
| Package / Case | Cylinder, Wire Leads |
| Resistance | 25 kOhms |
| Technology | Resistive |
| Termination Style | Wire Leads |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 241.86 | |
| 5 | $ 237.02 | |||
| 10 | $ 226.75 | |||
Description
General part information
603R25KL.25
Resistive Sensor Linear Position Shaft Wire Leads
Documents
Technical documentation and resources
No documents available
