E2E-X10MY2-53-US
ObsoleteOmron Automation and Safety
SENSOR PROX INDUCTIVE 10MM CYL
E2E-X10MY2-53-US
ObsoleteOmron Automation and Safety
SENSOR PROX INDUCTIVE 10MM CYL
Description
General part information
E2E-X10MY2-53-US
SENSOR PROX INDUCTIVE 10MM CYL
Technical Specifications
Parameters and characteristics for this part
| Specification | E2E-X10MY2-53-US |
|---|---|
| Indicator | LED |
| Ingress Protection | NEMA 1, IP67, 6, 12, 13, 4 |
| Material - Body | Nickel-Plated Brass |
| Operating Temperature (Max) | 85 °C |
| Operating Temperature (Min) | -40 °C |
| Output Type | SCR-NC, 2-Wire |
| Package / Case | Cylinder, Threaded - M18 |
| Response Frequency | 25 Hz |
| Sensing Distance | 0.394 " |
| Sensor Type | Inductive |
| Shielding | Unshielded |
| Termination Style | Cable Leads |
| Voltage - Supply (Maximum) | 120 V |
| Voltage - Supply (Minimum) | 100 VAC |
