Specification	0387007501

Barrier Type	2 Wall (Dual)
Bottom Termination	PC Pin
Color	Black
Current Rating	20 A
Material - Insulation	Thermoplastic
Mounting Type	Through Hole
Number of Circuits	1
Number of Rows	1
Number of Wire Entries	1
Operating Temperature (Max)	130 °C
Operating Temperature (Min)	-40 °C
Terminal Block Type	Barrier Block
Terminal Screw Finish	Clear Chromate, Zinc
Terminal Screw Material	Steel
Top Termination	Screws with Captive Plate
Voltage Rating	300 VAC/DC
Wire Gauge (AWG) (Max)	22 AWG
Wire Gauge (AWG) (Min)	14 AWG

038700 Series

...

Part	Number of Rows	Bottom Termination	Terminal Block Type	Voltage Rating	Barrier Type	Color	Current Rating	Number of Circuits	Pitch	Wire Gauge (AWG) (Min)	Wire Gauge (AWG) (Max)	Top Termination	Number of Wire Entries	Material Flammability Rating	Terminal Screw Material	Terminal Screw Finish	Operating Temperature	Material - Insulation	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Features
Molex 0387008114	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	15 A	14	0.325 in	12 AWG	22 AWG	Screws	14	UL94 V-0	Steel	Chromate Zinc	110 °C	Thermoplastic	Through Hole
Molex 0387007519	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	20 A	19	0.325 in	14 AWG	22 AWG	Screws with Captive Plate	19		Steel	Clear Chromate Zinc		Thermoplastic	Through Hole	130 °C	-40 °C
Molex 0387006309	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	15 A	9	0.325 in	14 AWG	22 AWG	Screws	9		Steel	Clear Chromate Zinc		Thermoplastic	Through Hole	130 °C	-40 °C
Molex 0387006602	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	15 A	2	0.325 in	12 AWG	22 AWG	Screws	2	UL94 V-0	Steel	Chromate Zinc	110 °C	Thermoplastic	Through Hole
Molex 0387007816	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	20 A	16	0.325 in	12 AWG	22 AWG	Screws with Captive Plate	16	UL94 V-0			110 °C	Thermoplastic	Through Hole
Molex 0387007302	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	15 A	2	0.325 in	14 AWG	22 AWG	Screws with Captive Plate	2		Steel	Clear Chromate Zinc		Thermoplastic	Chassis Panel Through Hole	130 °C	-40 °C	Flange
Molex 0387006119	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	15 A	19	0.325 in	14 AWG	22 AWG	Screws	19		Steel	Clear Chromate Zinc		Thermoplastic	Chassis Panel Through Hole	130 °C	-40 °C	Flange
Molex 0387000303	1	Closed	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	15 A	3	0.325 in	12 AWG	22 AWG	Screws	3	UL94 V-0	Steel	Chromate Zinc	110 °C	Thermoplastic	Chassis Panel
Molex 0387006109	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	15 A	9	0.325 in	14 AWG	22 AWG	Screws	9		Steel	Clear Chromate Zinc		Thermoplastic	Chassis Panel Through Hole	130 °C	-40 °C	Flange
Molex 0387008706	1	PC Pin	Barrier Block	300 VAC/DC	2 Wall (Dual)	Black	20 A	6	0.325 in	12 AWG	22 AWG	Screws with Captive Plate	6	UL94 V-0			110 °C	Thermoplastic	Through Hole
