PFC333232DH-661MHF
ActiveITG Electronics, Inc.
PFC CHOKE 660.0UH 14.8A 173.7M
PFC333232DH-661MHF
ActiveITG Electronics, Inc.
PFC CHOKE 660.0UH 14.8A 173.7M
Description
General part information
PFC333232DH-661MHF
660 µH Unshielded Wirewound Inductor 5.8 A 173.7mOhm Max Radial, Horizontal, 4 Leads
Technical Specifications
Parameters and characteristics for this part
| Specification | PFC333232DH-661MHF |
|---|---|
| Current - Saturation (Isat) | 7 A |
| Current Rating | 5.8 A |
| DC Resistance (DCR) (Max) | 173.7 mOhm |
| Height - Seated (Max) | 1.244 in |
| Inductance | 660 µH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Alloy Powder |
| Mounting Type | Through Hole |
| Operating Temperature (Max) | 150 °C |
| Operating Temperature (Min) | -55 °C |
| Package Leads | 4 Leads |
| Package Name | Radial, Horizontal |
| Shielding | Unshielded |
| Size / Dimension Length | 1.299 in |
| Size / Dimension Width | 1.259 in |
| Tolerance | 20 % |
| Type | Wirewound |
