1010387
ActiveIntegrated Power Designs
AC/DC CONVERTER 5V 24V 40W
1010387
ActiveIntegrated Power Designs
AC/DC CONVERTER 5V 24V 40W
Description
General part information
1010387
Open Frame AC DC Converters 2 Output 5V 24V 100 ~ 240 VAC Input
Technical Specifications
Parameters and characteristics for this part
| Specification | 1010387 |
|---|---|
| Applications | ITE (Commercial), Industrial, Medical |
| Approval Agency | cURus, UKCA, TUV, CE |
| Current - Output 1 | 5 A |
| Current - Output 2 | 1.5 A |
| Efficiency | 73 % |
| Features | Universal Input, Adjustable Output |
| Mounting Type | Chassis Mount |
| Number of Outputs | 2 |
| Operating Temperature (Max) | 70 °C |
| Operating Temperature (Min) | 0 °C |
| Power (Watts) | 40 W |
| Size / Dimension Height | 1.2 in |
| Size / Dimension Length | 4.25 in |
| Size / Dimension Width | 2.5 in |
| Standard Number | 60601-1, 62368-1 |
| Type | Open Frame |
| Voltage - Input (AC) Maximum | 240 VAC |
| Voltage - Input (AC) Minimum | 100 VAC |
| Voltage - Output 1 | 5 V |
| Voltage - Output 2 | 24 V |
